REL T/9x

TYPE

Front-firing active driver, down-firing passive

ACTIVE DRIVER SIZE & MATERIAL

10 in. (250mm) long-throw, FibreAlloy™ cone, inverted alloy centre cap, steel chassis

PASSIVE RADIATOR SIZE & MATERIAL

10 in. (250mm) long-throw, FibreAlloy™ cone, inverted alloy centre cap, steel chassis

LOW FREQUENCY EXTENSION

-6dB at 27 Hz

INPUT CONNECTORS

High Level Neutrik Speakon, Low Level (1) RCA, (1) LFE RCA

OUTPUT CONNECTORS

N/A

POWER OUTPUT

300 watts (RMS)

AMPLIFIER TYPE

Class A/B

WIRELESS CAPABILITY

REL Arrow (sold separately)

DUAL PARAMETRIC FILTER

N/A

FULLY ELECTRONIC SET SAFE

Yes

D.C. FAULT

Yes

OUTPUT SHORT

Yes

MAINS INPUT VOLTAGE

220-240 volts, 110-120 volts for certain markets

FUSES

3.15 Amp semi delay 230 volts operation, 6.3 Amp semi delay 115 volts operation

W X H X D

14.5 x 13.4 x 15.5 in., (370 x 340 x 393 mm)

NET WEIGHT

45.5 lbs. (20.6 kg)

FINISH

Piano Black Lacquer, Gloss White Lacquer 5 coats
