REL 212/SX

TYPE

(2) Front-firing active drivers, (1) rear passive, (1) down-firing passive

ACTIVE DRIVER SIZE & MATERIAL

(2) 12 in. (300mm) long throw, Continuous CastAlloy™ cone structure, die cast alloy chassis

PASSIVE RADIATOR SIZE & MATERIAL

Rear: 12 in. (300mm) Continuous CastAlloy™ cone structure, die cast alloy chassis; Down: 12 in. (300mm) Carbon/Carbon flat cone structure, steel chassis

LOW FREQUENCY EXTENSION

-6dB at 18 Hz

INPUT CONNECTORS

High Level Neutrik Speakon, Low Level (2) RCA, (1) LFE RCA, (1) LFE XLR

OUTPUT CONNECTORS

High Level Neutrik Speakon, (1) LFE RCA or (1) LFE XLR**

POWER OUTPUT

1,000 watts (RMS)

AMPLIFIER TYPE

NextGen 5 Class D

WIRELESS CAPABILITY

REL AirShip II (sold separately)

DUAL PARAMETRIC FILTER

N/A

FULLY ELECTRONIC SET SAFE

Yes

D.C. FAULT

Yes

OUTPUT SHORT

Yes

MAINS INPUT VOLTAGE

220-240 volts, 1120-120 volts for certain markets

FUSES

7 Amp semi delay 220 volts operation, 15 Amp semi delay 120 volts operation

W X H X D

14 1/4in., x 33in., x 20 1/4 in., (362 x 838 x 514.5mm)

NET WEIGHT

128 lbs. (58 kg)

FINISH

Piano Black Lacquer
