Mcintosh MC303 3-Channel Solid State Amplifier

ELECTRONIC SPECIFICATIONS

• Power Output per Channel

  300W @ 2, 4 or 8 Ohms

• Number of Channels

  3

• Total Harmonic Distortion

  0.005%

• S/N below rated output

  112dB

• Dynamic Headroom

  1.8dB

• Damping Factor

  >40

• Rated Power Band

  20Hz to 20kHz

• Frequency Response

  +0, -0.25dB from 20Hz to 20,000Hz
  +0, -3dB from 10Hz to 100,000Hz

CONTROL

• Remote Power Control

  Yes

• Multi-Channel DB25 Cable

  No

GENERAL SPECIFICATIONS

• Circuit Configuration

  Push-Pull Complementary Autoformers

• Circuit Design

  Solid State

• Mono Bridge

  No

• Mono Parallel

  No

• Output Type

  Autoformer™

• Meters

  Yes

• Meter Light Switch

  Yes

• Balanced Input

  Yes

• Front Panel

  Glass with handles

• Illumination

  LED Fiber Optic

• Chassis Style

  Inverted

CONNECTIVITY

• Speaker Binding Post Type

  Yes

WEIGHTS & DIMENSIONS

• Unit Dimensions (W x H x D)

  17-3/4" (45.09cm) x 12-3/8" (31.43cm) (including feet) x 22" (55.88cm) (including front panel and cables)

• Unit Weight

  155 lbs (70.3 kg)

• Shipping Weight

  180 lbs(81.6 kg)
