Mcintosh C8 2-Channel Vacuum Tube Preamplifier
91303
€5.670,00
Pre-order
Quantity:
1
Pre-Order
Product Details
Brand:
Mcintosh
ELECTRONIC SPECIFICATIONS
Number of Channels
2
Total Harmonic Distortion
0.08%
Frequency Response
+0, -0.5dB from 20Hz to 20kHz
+0, -3dB from 15Hz to 100kHz
Maximum Volts Out (Balanced / Unbalanced)
16V RMS / 8V RMS
Sensitivity High Level (Balanced / Unbalanced)
900mV / 450mV
Sensitivity Phono (Moving Coil)
0.45mV
Sensitivity Phono (Moving Magnet)
4.5mV
Signal To Noise Ratio (High Level)
95dB
Signal To Noise Ratio (Moving Coil)
75dB
Signal To Noise Ratio (Moving Magnet)
80dB
Voltage Gain (High Level)
15dB
Voltage Gain (Moving Coil)
75dB
Voltage Gain (Moving Magnet)
55dB
Input Impedance (Balanced / Unbalanced)
44K ohm, 22K ohm
CONNECTIVITY
Balanced Input
1
Unbalanced Input
2
Phono Input Moving Coil
1 (adjustable)
Phono Input Moving Magnet
1 (adjustable)
Upgradeable Digital Audio Module
Yes: DA2 can be installed
Digital Coaxial Input
0
Digital Optical Input
0
Digital MCT Input
0
Digital USB Input
0
HDMI (ARC) Input
0
Digital AES/EBU Input
0
Balanced Fixed Output
0
Balanced Variable Output
1
Unbalanced Fixed Output
0
Unbalanced Variable Output
2
Headphone Output
1/4" High Drive
Input Level Match
Yes, +/- 6dB
Home Theater PassThru
Yes
Unbalanced Analog Connector Type
Standard
Service Port
1
CONTROL
Tone Controls
Bass and Treble
Tone Bypass and Input Assign
Yes
RS232 Control Input
Yes
Power Control Output
1 Main, 2 Trigger
Rear Panel Data Port
2
Rear Panel IR Sensor Input
Yes
GENERAL SPECIFICATIONS
Multi-Chassis or Single
Single
Output Meters
No
Vacuum Tube or Solid State
Vacuum Tube
Power Consumption (On)
50 Watts
WEIGHTS & DIMENSIONS
Unit Dimensions (W x H x D)
12-9/32" (31.2cm) x 7-5/8" (19.4cm) x 16-1/4" (41.3cm)
Unit Weight
18 lbs (8.2 kg)
Shipping Weight
25 lbs (11.3 kg)
