Two PL509 (EL519)
Two ECC83 (12AX7)
One ECC85 (6AQ8)
Frequency response: 3Hz-30Khz +0 -1dB
Signal-to-nosie ratio: 96dB
Distortion (I.M.D.): <0.2%
Harmonic Distortion: -3dB <0.5% 12Hz-60Kz
Input Sensitvity (unbalanced): 1.2V
Input Impedance (unbalanced): 25KΩ
Output Damping Factor: 20
One Line Input (RCA) or Balanced Input (XLR)*
Power output (20-20KHz): 100W into 4 & 8Ω
Weight: 15.3kg (34lb)
Length: 300mm (12”)
Width: 254mm (10”)
Height: 150mm (6”)
Power Consumption: 180 watts
240 volt / 110 Volt / 100 Volt
(depending on model)
