Anthem MCA 525 GEN 2
4.409,99 €piece
Available on backorder
| POWER OUTPUT (PER CHANNEL) (Continuous RMS, 20 Hz – 20 kHz, <1% THD) |
||||||||||
|
||||||||||
| INPUTS / OUTPUTS | ||||||||||
| Inputs | Single-Ended, Balanced, Relay Trigger (3.5-mm Mono Jack) | |||||||||
| Outputs | Speaker Binding Posts, Relay Trigger (3.5-mm Mono Jack) | |||||||||
| SWITCHES | ||||||||||
| Front Panel | Power (On/Off) | |||||||||
| Rear Panel | 3 On/Off Modes (Trigger, Manual, Auto) | |||||||||
| THD at 100W | ||||||||||
| at 1 kHz | 0.0010% | |||||||||
| at 20 kHz | 0.015% | |||||||||
| IMD at 100 W | ||||||||||
| ITU-R (19 kHz + 20 kHz) | 0.0005% | |||||||||
| SMPTE (60Hz + 7kHz) | 0.002% | |||||||||
| Frequency Response, 20 Hz to 20 kHz | ||||||||||
| open circuit | ± 0.1 dB | |||||||||
| 8Ω | ± 0.1 dB | |||||||||
| 4Ω | ± 0.1 dB | |||||||||
| 2Ω | ± 0.2 dB | |||||||||
| OTHER SPECIFICATIONS | ||||||||||
| SNR, IEC-A, ref. 225 W | 120dB | |||||||||
| Power Bandwidth, -3 dB at 200 W into 8 ohms | 90 kHz | |||||||||
| Slew Rate | 30 V/μs | |||||||||
| Damping Factor, 20 Hz to 1 kHz | 300 | |||||||||
| Channel Separation, 100 Hz to 10 kHz | >65dB | |||||||||
| Input Impedance (RCA / XLR) | 10 kΩ / 15 kΩ | |||||||||
| Input Sensitivity, 225 W into 8 Ω | 1.5 Vrms | |||||||||
| Voltage Gain | 29 dB | |||||||||
| POWER CONSUMPTION | ||||
| standby | idle | typical | high output | |
|---|---|---|---|---|
| MCA 525 (Gen. 2) | 2.0W | 80W | 550W | 1200W |
| MCA 325 (Gen. 2) | 1.4W | 47 W | 350W | 750W |
| MCA 225 (Gen. 2) | 1.0W | 35W | 240W | 500W |
| DIMENSIONS | ||
| Height | 6-5/8” (16.9 cm) | |
| Height with Rackmount Kit | 4U | |
| Width | 17-1/4″ (43.9 cm) | |
| Depth | 18-1/8″ (46 cm) | |
| WEIGHT | ||
| MCA 525 (Gen. 2) | 61 lbs (27.5 kg) | |
| MCA 325 (Gen. 2) | 43 lbs (19.5 kg) | |
| MCA 225 (Gen. 2) | 40 lbs (18 kg) | |
| POWER REQUIREMENTS | ||
| 220-240 V version: | In countries where the line voltage is 220, 230, or 240 V, this product operates from a single phase AC power source that supplies between 198 V and 264 V at a frequency of 50 Hz | |
| Finish |
Black ,Silver |
|---|
